HG1-Strawberry Grow Container

This innovative system grows strawberries in water-based nutrient solutions within controlled containers. It maximizes space, saves water, and ensures year-round production with optimal conditions. Ideal for urban farming and sustainable agriculture! Quote for the hydroponic shipping container for sale price now.

Send Inquiry DOWNLOAD CATALOG

Specifications of HG1-Strawberry Grow Container

Specification description		Quantity	Unit
Box Body Main Structure
Main structure	Standard 40-foot refrigerated container (high-density polyammonia ester insulation layer, with remarkable thermal insulation effect, reducing later operational energy consumption)	1	item
Internal supporting facilities	T-shaped aluminum base plate (enhances the structural stability , can be used as a ground water recycling system)	1	item
	Aluminum-zinc coated plate + laboratory-specific anti-slip floor mat
	Single-layer cleanroom partition panel
	Interior decoration + Single-sided logo on the box surface
Implant System
Planting module	1) Number of equipment tiers: 5-tier cultivation 2) Frame material: Powder-coated steel frame 3) Dimensions of single unit: 95000mm x 450mm (Length x Width) 4) Vertical tiered cultivation method, with operational pathways not affecting normal planting, harvesting, nutrient solution replenishment, and other operations by Homo sapiens personnel.	4	group
Planting tray	Planting trough + planting pot + plug	20	group
Fill light	Full-spectrum LED plant-specific supplemental lighting	120	group
Fertilization system	1) Kamoer 3-channel peristaltic pump (speed adjustable) 2) Special aluminum alloy mounting bracket	1	set
Mother liquor tank	Blue fertilizer mixing bucket 10L	3	piece
Water filter	Small laminated filter	1	piece
Nutrient solution storage tank	1) Material: PP material	1	set
Irrigation system	Irrigation pump + main branch pipelines + supporting facilities (pressure-compensating drip irrigation pipes)	1	set
Lighting fixture	LED waterproof lighting fixture	3	set
Auxiliary materials	Lines, pipes, and installation accessories	1	item
Monitoring System
Temperature and Humidity Sensor	[Product Brand] TECLION [Product Model] TKLN-WS-G/5 [DC power supply] 10-30VDC [Temperature measurement range] -40℃-80°C [Humidity measurement range] 0-100%RH [Long-term temperature stability] ≤0.1°C/year [Long-term humidity stability] ≤0.1%RH/year [Temperature resolution] 0.1°C [Humidity resolution] 0.1%RH [Output signal] RS485(Modbus Agreement) [Temperature accuracy] ±0.5°C(25°C) [Humidity Accuracy] +3%RH(5-95%RH，25°C)	1	set
Carbon dioxide sensor	[DC power supply] 9-30V DC [Measurement accuracy] ±1.5%FS [Output signal] RS485 ( Modbus Agreement)	1	set
Water quality pH sensor	[Measuring range] 0-14ph [Resolution] 0.01ph [Work pressure] 0-4bar [Protection Level] IP68 [Output signal] RS485(Modbus Agreemwnt)	1	set
Water conductivity sensor	[Measurement range] 0-20000μs/cm [Resolution] 0.01μs/cm [Measurement accuracy] ≤±3% [Work pressure] 0-4bar [Protection Level] IP68 [Output signal] RS485(Modbus Agreement)	1	set
Soil conductivity sensor	[Measurement range] 0-10000μs/cm [Measurement accuracy] ±3% [Resolution] 1μs/cm	1	set
Soil pH sensor	[Measuring range] 4-10PH [Resolution] 0.1PH [Measurement accuracy] ±0.5PH	1	set
Soil temperature and humidity sensor	[Product Brand] TECLION [DC power supply] 9-24VDC [Temperature measurement range] -40℃-80°C [Humidity measurement range] 0-100%RH [Temperature resolution] 0.1°C [Humidity resolution] 0.1% [Output signal] RS485(Modbus Agreement) [Temperature accuracy] ±0.5°C [Humidity Accuracy] 0-53%for±3% 53%-100%for±5%	1	set
Liquid level sensor		1	set
Control Eystem
Smart Management Control Platform	Control management system software, 1 set 1) Achieves management and detection display of various sensors such as temperature, humidity, CO2, etc. inside the plant factory. 2) Enables intelligent management of equipment including plant growth lights, humidification, fresh air systems, and constant temperature control.	1	set
Control cabinet	1) High-definition 10-inch Siemens brand LED screen + Siemens PLC main unit + remote control module + electronic components + cabinet body	1	set
Environmental Control Equipment
Constant temperature unit	Constant temperature cooling and heating unit (including 485 communication protocol module for intelligent unified management)	1	set
Fresh air system	Fresh air handling unit + supply and return air ducts + supply and return air vents + check valve	1	set
Interlayer ventilation	Interlayer breeze system	60	set
Dehumidifier		1	set
carbon dioxide	15L carbon dioxide steel cylinder + electromagnetic pressure reducing valve + supporting facilities	1	set
